Page 3
Publication 2727-IN004C-MU-P
Installation Instructions
MobileView Connection Cable
(Catalog Number 2727-MRT5, -MRT10, -MRT15, -MRT20)
English
The MobileView Connection Cable connects the following machine terminals to the
MobileView Junction Box (2727-MRJB1) via the MobileView Junction Box Cable
(2727-MREX1)
•
MobileView Guard G750
•
MobileView Machine Terminal MT750
The MobileView Connection Cable is available in the following lengths:
•
5 meter/16.4 foot (2727-MRT5)
•
10 meter/32.8 foot (2727-MRT10)
•
15 meter/49.2 foot (2727-MRT15)
•
20 meter/65.6 foot (2727-MRT20)
Inside. . .
MobileView Connection Cable .......................................................................................... 4
Connection Cable Diagram ................................................................................................ 4
Attaching the Connection Cable to the MobileView Terminal .......................................... 5
Connection Cable Compartment ........................................................................................ 6
Attaching Connection Cable for Left or Right-Hand Operation ......................................... 7
Connecting the MobileView Terminal to the Junction Box ............................................... 8
