Page 22
4-6 Connecting the Network Interface Card
Publication 1784-UM527B-EN-P - October 2003
2. Connect the 3-pin Phoenix end of the CP12 cable to the PKTx card.
3. Connect the 9-pin D-shell end directly to the 9-pin D-shell connector on the front of
the original PLC-5 processor.
4. Restore power to the computer.
20223a-M
3-pin Phoenix connector with
switchable termination resistor
10.5 ft.
(3.20 m)
1784-CP12 Cable
20223a
30172-M
Peer Communication
Interface Connector
1784-PKTx card
PLC-5 Family Processor
30172
