Install the 1784-PKTCS Card 2-3
Publication 1784-IN042A-EN-P - April 2005
4. Turn on the computer to be certain that it comes up correctly.
Connect to the Network
After you have installed the card, you can connect it:
• directly to a ControlNet network, which requires a tap (page 2-5)
• to a device already connected to the ControlNet network (page 2-6)
See Figure 2.1 on page 2-4 for the connectors and indicators.
If the computer:
then:
powers up
go on to the next section, Connect to the Network , on page 2-3
hangs up
either the card is not seated correctly in the PCI slot or you have a
memory or I/O conflict. You should:
• remove and reinsert the card into the same PCI slot and
try again
• remove and reinsert the card into a different PCI slot and
try again
• remove all other non-essential cards and try again
If you continue to experience difficulty, contact your local
Rockwell Automation sales representative or distributor, or call
Rockwell Automation Technical Support at 440.646.5800.
WARNING
If you connect or disconnect the ControlNet cable with power applied
to this module or any device on the network, an electrical arc can
occur. This could cause an explosion in hazardous location
installations.
