A - status indicators, Linking device, Ethernet/ip network – Rockwell Automation 1788-EN2DNR EtherNet/IP to DeviceNet Linking Device User Manual User Manual
Page 47: Devicenet network, Appendix a, Status indicators, Appendix

Rockwell Automation Publication 1788-UM059A-EN-P - August 2014
47
Appendix
A
Status Indicators
Linking Device
EtherNet/IP Network
DeviceNet Network
Indicator
Status
Description
MS
(Module Status)
Off
Green
Flashing green
Red
Flashing red
Alternating red/green
Orange
Repeating one flash orange
Repeating two flashes orange
Repeating three flashes orange
Power off
Normal operation
The module is not configured
Unrecoverable error
Recoverable error
Power-on self-test (POST)
Unrecoverable error: firmware has crashed
Unrecoverable error
Unrecoverable error
Unrecoverable error: firmware is not started
SD
(SD card Status)
Flashing green
Flashing red
Accessing SD card
Failure
Indicator
Status
Description
EN NS
(EtherNet/IP Status)
Off
Green
Flashing green
Red
Flashing red
Alternating green/red
Power off, or no IP address
Connected
Not connected
Duplicate IP address
Connection timeout
Power-on self-test (POST)
LNK 1, LNK 2
(Ethernet Link 1, 2)
Off
Flashing green
Flashing yellow
No link
Receiving/transmitting Ethernet packets at 100
Mbit
Receiving/transmitting Ethernet packets at 10
Mbit
Indicator
Status
Description
DN NS
(DeviceNet Status)
Off
Green
Flashing green
Red
Flashing red
Alternating green/red
No power
Online, connected
Online, not connected
Unrecoverable fault
Recoverable fault
Communication faulted
