12 Rockwell Automation Publication 1788-UM059A-EN-P - August 2014
Chapter 2 Install the Linking Device
Set the DeviceNet Node Address and Data Rate by Using RSNetWorx
for DeviceNet Software
See Set the DeviceNet Node Address and Data Rate on page 20 for information
about using RSNetWorx software to set node address and data rate.
Set the Linking Device
IP Address Four methods can be used to set the linking device IP address:
• Use the IP address rotary switches on the side of the linking device
• Use the DHCP protocol
• Use RSLinx Software
• Use the web pages of the linking device
Set the Linking Device IP Address by Using the Rotary Switches
The rotary switches are on the right side of the linking device.
Set the IP address according to the table below.
1 250 kbps
2 500 kbps
Other value Data rate selected via RSNetWorx
software
Switch Data Rate
Switch IP Address
000 Administrative mode
The linking device uses the IP address that was used last startup
The web pages are available
001 - 254 192.168.1.XYZ where XYZ is the value of the three switches
888 Reset the linking device to initial out-of-box settings
Other value The linking device starts in operating mode, using the latest configured IP
address
x100
x10
x1
