Rockwell Automation 1757-PIM ProcessLogix Pulse Input Module Installation User Manual
Page 9
ProcessLogix Pulse Input Module 9
Publication 1757-IN900A-US-P - February 2000
Continue with the following procedures to configure parameters on the
remaining tabs for the 1757-PIM, or click OK to accept only the changes
made so far and return to the Project tree.
Under the Server Parameters tab (see figure below), enter the appropriate
information such as filenames for desired display templates (Point Detail
Page, Group Detail Page and Associated Displays), along with values for
appropriate parameters such as for Control Level, Control Area, and EU
HI/EU LO parameters. If necessary, press F1 to access on-line help for
assistance during this step.
