Rockwell Automation 1757-PIM ProcessLogix Pulse Input Module Installation User Manual
Page 8
8 ProcessLogix Pulse Input Module
Publication 1757-IN900A-US-P - February 2000
Continue with the following procedures to configure parameters on the
remaining tabs for the 1757-PIM, or click OK to accept only the changes
made so far and return to the Project tree.
Under the Status/Data tab (see figure below), enter desired values for
configuration parameters. If necessary, press F1 to access on-line help for
assistance during this step.
