12 ProcessLogix Pulse Input Module
Publication 1757-IN900A-US-P - February 2000
Parameter Specification
Vibration:
Operating/Storage Vibration
(3 axes):
Transportation Band Vibration
(3 axes):
• Frequency: 10-60Hz
•
Acceleration: 0.5g Max.
• Displacement: 0.1 inches (0.254cm)
•
Frequency: 0-60Hz
• Acceleration: 1g Max.
•
Displacement: 0.1 inches (0.254cm)
Mechanical Shock:
Operating/Storage Shock:
Transportation Shock:
•
Acceleration: 5g Max.
• Duration: 30ms Max.
• Acceleration: 20g Max.
• Duration: 30ms Max.
Barometric Pressure:
Operating/Storage Altitude:
Transportation Band Altitude:
-300 to +3000m (-984 to 9843 ft.)
Any
Corrosives:
With enclosure:
Enclosure external temperature
limits:
G2 standard, G3 option (ISA S71.04)
TBD
CE Mark Standard
Compliance:
Yes
Electromagnetic Interference: 15V/m, SAMA Standard PMC 33.3-1978
Class 2 or same as CE Mark
(whichever is more severe)
Electrostatic Discharge: Same as CE Mark, IEC801-2, plus 15kV to enclosure, controller surfaces
and min. 10kV to all field wires.
Surge Protection: Same as CE Mark, IEC801-4 and 5 or IEEE SWC 472-1989 (whichever is
more severe)
