Rockwell Automation 1756-HIST2G FactoryTalk Historian ME 2.1 Installation Instructions User Manual
Page 8
8 FactoryTalk Historian Machine Edition Module
Publication
1756-IN611A-EN-P - February 2010
Identify FactoryTalk Historian ME Module Components
Use the following figures to identify the external features of the FactoryTalk
Historian ME Module.
FactoryTalk Historian ME Module Front View
In the following figure, the FactoryTalk Historian ME Module is shown from
the front view with the four-character LED display, LED indicators (BAT,
STS, OK), and Ethernet port locations identified.
