24 FactoryTalk Historian Machine Edition Module
Publication 1756-IN611A-EN-P - February 2010
Specifications
Cat. No. 1756-HIST1G | 1756-HIST2G
Environmental Conditions
Operating
Temperature IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0…60 °C (32…140 °F)
Non-operating
Temperature IEC 60068-2-1 (Test Ab, Unpackaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Non-operating Dry
Heat),
IEC 60068-2-14 (Test Na, Unpackaged Non-operating
Thermal Shock):
-40…85 °C (-40…185 °F)
Relative Humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% noncondensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
2g @ 10…500 Hz
Operating Shock IEC 60068-2-27 (Test Ea, Unpackaged Shock):
30g
Non-operating
Shock IEC 60068-2-27 (Test Ea, Unpackaged Shock):
50g
Emissions CISPR 11:
Group 1, Class A
ESD Immunity IEC 61000-4-2:
4kV contact discharges
8kV air discharges
Radiated RF
Immunity IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80…2000MHz
1V/m with 1 kHz sine-wave 80% AM from
2000…2700MHz
EFT/B Immunity IEC 61000-4-4:
±1 kV at 5 kHz on communications ports
Surge Transient
Immunity IEC 61000-4-5:
±1 kV line-earth(CM) on communications ports
Conducted RF
Immunity IEC 61000-4-6:
10V/rms with 1 kHz sine-wave 80% AM from 150
kHz…80MHz
