FactoryTalk Historian Machine Edition Module 25
Publication 1756-IN611A-EN-P - February 2010
Allen-Bradley and ControlLogix are trademarks of Rockwell Automation.
Ethernet is a trademark of Digital Equipment Corporation, Intel, and Xerox Corporation.
All supply voltages
and/or current
ratings. 5.1 V DC @ 800 mA
24 V DC @ 3 mA
Isolation Voltage 30V (continuous), Basic Insulation Type. Type tested at
500V AC for 60 s, Ethernet to System
Wire Size Ethernet connections:
RJ45 connector according to IEC 60603-7, 2 or 4 pair
Category 5e minimum cable according to TIA 568-B.1 or
Category 5 cable according to ISO/IEC 24702
Wiring Category
1 2 - on communications ports
North American
Temp Code T4
Certifications
2
(when product is marked)
c-UL-us: UL Listed Industrial Control Equipment, certified
for US and Canada
c-UL-us: UL Listed for Class I, Division 2 Group A,B,C,D
Hazardous Locations, certified for U.S. and Canada
CE: European Union 2004/108/EC EMC Directive,
compliant with:
EN 61326-1; Meas./Control/Lab, Industrial
Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8,
Zone A & B)
C-Tick: Australian Radiocommunications Act, compliant
with:
AS/NZS CISPR 11; Industrial Emissions
1
Use this Conductor Category information for planning conductor routing. Refer to
publication 1770-4.1, “Industrial Automation Wiring and Grounding Guidelines”.
2
See the Product Certification link at www.ab.com for Declarations of Conformity,
Certificates, and other certification details.
Cat. No. 1756-HIST1G | 1756-HIST2G
