background image

20 FactoryTalk Historian Machine Edition Module

Publication

1756-IN611A-EN-P - February 2010

Application Status

The Application Status is composed of four application subsystems, as
described in the following table.

Note: If more than one of the four statuses exist, then they are displayed one
after another with a two second duration between each message.

Application Subsystem

Status

Description

Configuration status

A. Not configured

B. No points

If neither Data Transfer
or Data Collection is
configured, then the “Not
configured” status is
displayed. Otherwise, the
status is empty. Note:
Data Collection is not
configured if the number
of subscribed points from
the data server is zero
(0). If Data Collection

is

not configured, but Data
Transfer

is configured,

then the configuration
status is “No points.”
Otherwise, the status is
empty. Note:

Data

Transfer is not
configured if the SE Host
Server Name or IP
address is not entered or
is not resolved. The
status is “No upload.”
