Step 1: verify that you have all the components – Rockwell Automation 1756-Mx ControlLogix Memory Board Installation Instructions User Manual
Page 5
ControlLogix™ Memory Board 5
Publication 1756-IN033B-EN-P - November 2000
Step 1: Verify that You Have All the Components
A. Locate the following components:
B. Make sure that you have the correct memory board:
Component:
Description:
memory board
memory board label
catalog number labels
The catalog numbers on your labels may be different
from the ones that are shown.
If you have this controller:
Then you can:
1756-L1
add one of these memory boards:
•
1756-M1
•
1756-M2
•
1756-M3
1756-L1Mx
replace the existing memory board with one of these memory
boards:
•
1756-M1
•
1756-M2
•
1756-M3
1756-L55Mx
replace the existing memory board with one of these memory
boards:
•
1756-M13
•
1756-M14
•
1756-M16
40042
1756-L1
1756-L1M1
1756-L1M2
