What You Need to Do
To guard against ESD damage, take these precautions:
To install the memory board, do these steps:
•
Step 1: Verify that You Have All the Components
•
Step 2: Remove the Controller from the Chassis
•
Step 3: Remove the Side Plate of the Controller
•
Step 4: Remove the Existing Memory Board (If Any)
•
Step 5: Install the Memory Board
•
Step 6: Replace the Side Plate
•
Step 7: Attach Labels
ATTENTION
!
Electrostatic discharge can damage the components. Follow
these guidelines:
•
touch a grounded object to discharge potential static
•
wear an approved grounding wriststrap
•
do not touch connectors or pins on component boards
•
do not touch circuit components inside the controller
•
if available, use a static-safe work station
•
when not in use, store each component in the anti-static
packaging in which it was shipped
