ControlLogix™ Memory Board 13
Publication 1756-IN033B-EN-P - November 2000
Specifications
Table A 1756-L1, -L1Mx Controller
Description: Value:
1756-L1 1756-L1M1 1756-L1M2 1756-L1M3
user available memory (1)
(1) Amount of memory available after RSLogix 5000 software is connected and a null project is loaded
64K bytes 512K bytes 1M bytes 2M bytes
peak backplane current
+5V dc
+24V dc 0.65A
0.02A 0.95A
0.02A 1.05A
0.02A 1.20A
0.02A
average power dissipation 3.3W 4.6W 4.8W 5.4W
average thermal dissipation 11.3 BTU/hr 15.6 BTU/hr 16.4 BTU/hr 18.4 BTU/hr
operating temperature 0° to 60° C (32 to 140° F)
storage temperature -40° to 85° C (-40 to 185° F)
relative humidity 5% to 95% noncondensing
vibration 10 to 500 Hz
2.0 G maximum peak acceleration
operating shock 30G peak for 11ms
storage shock 50G peak for 11ms
additional environmental
requirements
•
This product must be mounted within a suitable enclosure to prevent
personal injury resulting from accessibility to live parts. The interior
of this enclosure must be accessible only by use of a tool.
•
This industrial control equipment is intended to operate in a
Pollution Degree 2 environment, in overvoltage category II
applications, (as defined in IEC publication 664A) at altitudes up to
2000 meters without derating.
weight 10.0 oz. 12.5 oz. 12.5 oz. 12.7 oz.
programming cable 1756-CP3 or 1747-CP3 serial cable
category 3
(2)
(2) See Industrial Automation Wiring and Grounding Guidelines , publicaton 1770-4.1.
battery 1756-BA1 (PROMARK Electronics 94194801)
0.59g lithium
documentation set 1756-DPALEN
