FLEX I/O 8 Output HART Analog Module 21
Publication 1794-IN109D-EN-P - January 2014
Chn: HART Loop Status:
Bit 0: HART enable
Bit 1: Device Connected
Bit 2: Response Error
Bit 3: CMD 48 Update
Bit 4: HART Loop Tolerance Error
Bit 5: HART Update
Bit 6: HART message
Bit 7:
0: Disabled
0: Not Connected
0: No HART message
failure
0: CMD 48 not
updated
0: No HART Current
Fault
0: HART Device
information not
updated
0: No new message
1: Enabled
1: Connected
1: Response ended in error
1: CMD 48 updated
1:HART Current Fault
1: HART Device information
updated since last read
1: HART user message queue
has completed a message
Reserved
Where PVA = The primary variable for this channel has been acquired.
SVA = The secondary variable for this channel has been acquired.
TVA = The tertiary variable for this channel has been acquired.
FVA = The fourth (quaternary) variable for this channel has been acquired.
HART Read Back Threshold
HART Read Back Decimal Bits
Value 7 6 5 4 3
15 14 13 12 11
Disabled 0 0 0 0 0 0
Not applicable (1) 1 0 0 0 0 1
Not applicable 2 0 0 0 1 0
Not applicable 3 0 0 0 1 1
Not applicable 4 0 0 1 0 0
5% 5 0 0 1 0 1
6% 6 0 0 1 1 0
7% 7 0 0 1 1 1
8% 8 0 1 0 0 0
HART Input Data Descriptions
