18 FLEX I/O 8 Output HART Analog Module
Publication 1794-IN109D-EN-P - January 2014
28 Ch2 HART Primary Value
29
30 Ch2 HART Secondary Value
31
32 Ch 2 HART Tertiary Value
33
34 Ch2 HART Fourth Value
35
36 Ch2 HART Secondary Value Units Code Ch2 HART Primary Value Units Code
37 Ch2 HART Fourth Value Ch2 HART Tertiary Value Units Code
38 Ch3 HART Field Device Status Ch3 HART Communication Status
39 Reserved Ch0 HART Loop Status
40 Ch3 HART Primary Value
41
42 Ch3 HART Secondary Value
43
44 Ch3 HART Tertiary Value
45
46 Ch3 HART Fourth Value
47
48 Ch3 HART Secondary Value Units Code Ch3 HART Primary Value Units Code
49 Ch3 HART Fourth Value Ch3 HART Tertiary Value Units Code
50 Ch4 HART Field Device Status Ch4 HART Communication Status
51 Reserved Ch4 HART Loop Status
52 Ch4 HART Primary Value
53
54 Ch4 HART Secondary Value
55
56 Ch4 HART Tertiary Value
57
HART Input Data
Word Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
