FLEX I/O 8 Output HART Analog Module 17
Publication 1794-IN109D-EN-P - January 2014
HART Input Data
Word Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 Reserved Ch7 Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0
(HART Communications Status)
1 Reserved
2 Ch0 HART Field Device Status Ch0 HART Comm Status
3 Reserved Ch0 HART Loop Status
4 Ch0 HART Primary Value
(IEEE 754-1985 Single-Precision 32 bit floating point)
5
6 Ch0 HART Secondary Value
(IEEE 754-1985 Single-Precision 32 bit floating point) 7
8 Ch0 HART Tertiary Value
(IEEE 754-1985 Single-Precision 32 bit floating point) 9
10 Ch0 HART Fourth (Quaternary) Value
(IEEE 754-1985 Single-Precision 32 bit floating point) 11
12 Ch0 Secondary Value Units Code Ch0 Primary Value Units Code
13 Ch0 Fourth Value Units Code Ch0 Tertiary Value Units Code
14 Ch1 HART Field Device Status Ch1 HART Communication Status
15 Reserved Ch1 HART Loop Status
16 Ch1 HART Primary Value
17
18 Ch1 HART Secondary Value
19
20 Ch1 HART Teritiary Value
21
22 Ch1 HART Fourth Value
23
24 Ch1 HART Secondary Value Units Code Ch1 HART Primary Value Units Code
25 Ch1 HART Fourth Value Ch1 HART Tertiary Value Units Code
26 Ch2 HART Field Device Status Ch2 HART Communication Status
27 Reserved Ch2 HART Loop Status
