Installing Your Module
All modules are mounted in a single slot. Remember that in a modular system the
processor always occupies the first slot of the first chassis.
1. Verify that all switches are set correctly for the application.
2. Align the circuit board of the analog module with the card guide of the
chassis as shown on page 12.
3. Slide the module in until both top and bottom retaining clips are secured.
4. To remove the module, depress the retaining clips at the top and bottom of
the module and slide the module out.
ATTENTION
Never install, remove, or wire modules with power applied to
the chassis. Also, do not expose analog modules to surfaces or
other areas that may typically hold an electrostatic charge.
Electrostatic charges can destroy the analog circuitry.
IMPORTANT
The potentiometer sets the voltage during factory calibration to
2.5 volts. It is set and sealed at the factory and does not
require any adjustments.
ATTENTION
Care should be taken to avoid connecting a voltage source
without a current transmitter, etc. to a channel configured for
current input. Improper module operation or damage to the
module can occur.
