16 Axis PCI SERCOS interface Card 21
Publication 1784-IN041A-EN-P – June 2003
Ring Topology
The SERCOS network consists of a Master (1784-PM16SE card) and several
slaves (drives) connected in a ring topology. The fiber optical ring starts and
ends with the master.
The following diagram gives an example of a possible network connected in
a ring topology.
2094-AM02 Kinetix 6000 15A Drive, 230VAC
2094-BC01-M01 Kinetix 6000 6KW Power Supply/9A Drive, 460VAC
2094-BC02-M02 Kinetix 6000 15KW Power Supply/15A Drive, 460VAC
2094-BM01 Kinetix 6000 9A Drive, 460VAC
2094-BM02 Kinetix 6000 15A Drive, 460VAC
2098-DSD-005-SE Ultra3000 0.5KW SERCOS interface 230VDrive
2098-DSD-010-SE Ultra30001KW SERCOS interface 230VDrive
2098-DSD-020-SE Ultra3000 2KW SERCOS interface 230VDrive
2098-DSD-030-SE Ultra3000 3KW SERCOS interface 230VDrive
2098-DSD-075-SE Ultra3000 7.5KW SERCOS interface 230VDrive
2098-DSD-150-SE Ultra3000 15KW SERCOS interface 230VDrive
2098-DSD-HV030-SE Ultra3000 3KW, 460VAC SERCOS interface 460V drive
2098-DSD-HV050-SE Ultra3000 5KW, 460VAC SERCOS interface 460V drive
2098-DSD-HV100-SE Ultra3000 10KW, 460VAC SERCOS interface 460V drive
2098-DSD-HV150-SE Ultra3000 15KW, 460VAC SERCOS interface 460V drive
2098-DSD-HV220-SE Ultra3000 22KW, 460VAC SERCOS interface 460V drive
8720MC 8720MC High Performance Drive
Catalog Number Description
