2 16 Axis PCI SERCOS interface Card
Publication 1784-IN041A-EN-P – June 2003
Important User Information
Because of the variety of uses for the products described in this publication,
those responsible for the application and use of these products must satisfy
themselves that all necessary steps have been taken to assure that each
application and use meets all performance and safety requirements,
including all applicable laws, regulation codes, and standards. In no event will
Rockwell Automation be responsible or liable for indirect or consequential
damage resulting from the use or application of these products.
The illustrations, charts, sample programs, and layout examples shown in
this publication are intended solely for purposes of example. Since there are
many variables and requirements associated with any particular installation,
Rockwell Automation does not assume responsibility or liability (to include
intellectual property liability) for actual use based upon the examples shown
in this publication.
See page:
Important User Information 2
Rockwell Automation Support 4
Related Documentation 5
Overview 6
Environment and Enclosure 6
Preventing Electrostatic Discharge 8
Identifying Card Components 8
Hazardous Location Information 11
Installing the card 13
Fiber Optic Transmission 16
Fiber Optic Cables 17
Supported Drives 21
Ring topology 22
LED Indicators 23
Card Specifications 26
