Compact I/O High-speed Counter Module 29

Publication 1769-IN030B-EN-P - October 2010

EFT/B immunity

IEC 61000-4-4

±2 kV at 5 kHz on power ports
±2 kV at 5 kHz on signal ports

Surge transient immunity

IEC 61000-4-5

±1 kV line-line (DM) and ±2 kV line-earth (CM)
on power ports
±1 kV line-line (DM) and ±2 kV line-earth (CM)
on signal ports
±1 kV line-earth (CM) on shielded ports

Conducted RF immunity

IEC 61000-4-6

10V rms with 1 kHz sine-wave 80% AM from
150 kHz…80 MHz

(1)

This rating applies for your system if a relay module, such as the 1769-OW8, is used.

Certifications - 1769-HSC

(1)

(1)

When product is marked.

Certification

(2)

(2)

See the Product Certification link at

http://www.ab.com

for Declarations of Conformity, Certificates, and other

certification details.

1769-HSC

c-UL-us

UL Listed Industrial Control Equipment, certified for
U.S. and Canada. See UL File E65584

c-UL-us

UL Listed for Class I, Division 2 Group A,B,C,D
Hazardous Locations, certified for U.S. and Canada. See
UL File E321922

CE

European Union 2004/108/EC EMC Directive, compliant
with:
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8,

Zone A & B)

C-Tick

Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions

Environmental Specifications - 1769-HSC

Attribute

1769-HSC
