28 Compact I/O High-speed Counter Module
Publication 1769-IN030B-EN-P - October 2010
Environmental Specifications - 1769-HSC
Attribute 1769-HSC
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0…60 °C (32…140 °F)
Temperature, surrounding air, max 40 °C (104 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating
Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating
Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged
Nonoperating Thermal Shock)
-40…85 °C (-40…185 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat)
5...95% noncondensing
Vibration, operating
IEC 60068-2-6 (Test Fc, Operating)
5 g @ 10...500 Hz, peak-to-peak
Vibration, relay operation
IEC 60068-2-6
2 g @ 10…500 Hz (1)
Shock, operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock)
30 g, 11 ms panel mounted
20 g, 11 ms DIN rail mounted
Shock, nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock)
40 g, panel mounted
30 g, DIN rail mounted
Emissions
CISPR 11
Group 1, Class A
ESD immunity
IEC 61000-4-2
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from
80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM at
900 and 1890 MHz
10V/m with 1 kHz sine-wave 80% AM from
2000…2700 MHz
