24 Compact I/O High-speed Counter Module

Publication 1769-IN030B-EN-P - October 2010

Maximum Output Current per Point - 5V DC Operation

Maximum Output Current per Module - 5V DC Operation

Temperature

Derated Current

0…40 °C (-32…104 °F)

1 A

60 °C (140 °F)

0.5 A

Temperature

Derated Current

0…40 °C (-32…104 °F)

4 A

60 °C (140 °F)

2.0 A

(-32)

(50)

(68)

(86)

(104)

(122)

(140)

(158)

Current Derating Based on Temperature

Ambient Temperature, °C (°F)

0.5 A at 60 °C (140 °F)

45206

Cu

rrent per Point

(A)

(-32)

(50)

(68)

(86)

(104)

(122)

(140)

(158)

Current Derating Based on Temperature

Ambient Temperature, °C (°F)

2 A at 60 °C (140 °F)

45207

Curre

nt p

er Modu

le

(A

)
