Wire the Module
The following sections describe how to connect the voltage supply and connect the inputs and
outputs.
Connect the Voltage Supply
To comply with CE Low Voltage Directives (LVD) and UL restrictions, you must use either a
Safety Extra Low Voltage (SELV), or a Protected Extra Low Voltage (PELV) power supply to
power this module. A SELV supply cannot exceed 30V rms, 42.4V peak, or 60V DC under
normal conditions and under single-fault conditions. A PELV supply has the same rating and is
connected to protected earth.
The supply voltage is connected via a 4-pin connector that accommodates wire sizes up to
2.5 mm
2
(14 AWG). You need to connect only one wire to L+ and one wire to L-. Both L+ and
L- terminals are internally connected, so you can daisy-chain 24V DC power from the module to
other devices in the panel by using the remaining terminal.
Operating Voltage Supply
Eight channels comprise one group, with each group having its own operating voltage supply.
Both group 1 and group 2 must be connected to the voltage supply. In addition, both L-/L- and
L+1/L+1 must be connected when using group 1 and both L-/L- and L+2/L+2 must be
connected when using group 2. A jumper will suffice.
IMPORTANT
Protect the module with a 10 A slow-blow fuse.
ATTENTION: Do not reverse the L+ and L- terminals or damage to the module
will result. There is no reverse polarity protection.
IMPORTANT
The total current consumption of each group must not exceed 8 A. If the total
current exceeds 8 A, the group is shut down and then reconnected cyclically.
Group
Supply Terminals
Output Channels
24V DC - 1:
L-, L-, L+1, L+1
DO1:
1, 2, 3, 4 and 9, 10, 11, 12
24V DC - 2:
L-, L-, L+2, L+2
DO2:
5, 6, 7, 8 and 13, 14, 15, 16
