About the module, General safety, Preventing electrostatic discharge – Rockwell Automation 1753-OB16 GuardPLC Digital Output Module Installation Instructions User Manual
Page 3
GuardPLC Digital Output Module 3
Rockwell Automation Publication 1753-IN005B-EN-P - June 2010
About the Module
The 1753-OB16 digital output module is a 16-channel output module for use with
GuardPLC controllers.
General Safety
Preventing Electrostatic Discharge
ATTENTION: Personnel responsible for the application of safety-related
programmable electronic systems (PES) shall be aware of the safety
requirements in the application of the system and shall be trained in using the
system.
ATTENTION: This equipment is sensitive to electrostatic discharge, which can
cause internal damage and affect normal operation. Follow these guidelines
when you handle this equipment:
•
Touch a grounded object to discharge static potential.
•
Wear an approved wrist-strap grounding device.
•
Do not touch connectors or pins on component boards.
•
Do not touch circuit components inside the equipment.
•
Use a static-safe workstation, if available.
•
Store the equipment in appropriate static-safe packaging when not in use.
Digital
Outputs
Voltage Supply
Connection
Ethernet Ports
(on bottom of controller)
Voltage Supply Connection
Digital
Outputs
Digital
Outputs
Digital
Outputs
