Chapter 2
Configuring Passwords and Privileges

2-9

As system administrator, you can assign read and write privileges for each
program file in a processor in order to limit the ability of users to view or
change it.

Important:

•

You cannot modify read and write privileges to system (file 0) or
undefined files.

•

Removing both read and write access from class 1 for a program file
prevents even you, the system administrator, from accessing that file.
Make sure that class 1 retains whatever access is necessary to each file.

•

Download screening for DTEP violations is directed at program files for
which classes 2-4 have write privileges. If you generate files offline that
control critical logic, you must remove all privileges to write to these files
from classes 2-4 before DTEP will let you download the files.

To specify read and write privileges for a program file, follow the steps on
the left.

+= PROGRAM FILE PRIVILEGES ======================================[ OFFLINE ]===+

| File Name Type Class1 Class2 Class3 Class4 |

|––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––|

| 0 system RW RW RW RW |

| 1 undefined RW RW RW RW |

| 2 ladder RW RW RW RW |

| |

+==============================================================================+

Press a function key to toggle the privilege.

Rem Prog PLC–5/46 Series C Revision G 5/46 File PROTECT

Toggle

Priv

F10

If you want the class to be able to:

Select this option:

Read the program file only

Read and change the program file

Neither read nor modify the program file

(Blank)

①

You can use this to protect proprietary algorithms from being viewed.

Processor

Functions

Toggle

Privileges

Cursor to Intersection

of File Description and

Privilege Class

Modify

Privileges

6200

Main Menu

Online

Program

Offline

Program

F10

Assigning Read and Write
Privileges for a Program File
