26 CompactBlock Distributed I/O on Remote I/O
Publication 1791R-IN001A-EN-P - February 2002
General Specifications (continued)
Vibration IEC60068-2-6 (Test Fc, Operating):
5g @ 10-500Hz
Conductors Wire Size
Category
14 gauge (2mm 2 ) stranded maximum
3/64 inch insulation maximum
2
1, 2
ESD Immunity IEC 61000-4-2:
6kV contact discharge
8kV air discharge
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 80MHz to
1000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
EFT/B Immunity IEC 61000-4-4:
±2kV at 5kHz on signal ports
±2kV at 5kHz on communications ports
Surge Transient Immunity IEC 61000-4-5:
± 1kV line-line(DM) and ± 2kV line-earth(CM) on
signal ports
± 2kV line-earth(CM) on shielded ports
Conducted RF Immunity IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz
to 80MHz
Emissions CSPR 11:
Group 1, Class A
Certifications:
(when product is marked) c-UL-us UL Listed Industrial Control Equipment,
certified for US and Canada
c-UL-us UL Listed for Class I, Division 2 Group
A,B,C,D Hazardous Locations, certified for
U.S. and Canada
CE 3 European Union 89/336/EEC EMC
Directive, compliant with:
EN 50081-2; Industrial Emissions
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial
Requirements
61000-6-2; Industrial Immunity
C-Tick 3 Australian Radiocommunications Act,
compliant with:
AS/NZS 2064; Industrial Emissions
Enclosure Meets IP20
1. You use this conductor category information for planning conductor routing as
described in the system level installation manual.
2. See publication 1770-4.1, “Programmable Controller Wiring and Grounding
Guidelines.”
3. See the Product Certification link at www.ab.com for Declarations of Conformity,
Certificates, and other certification details.
