CompactBlock Distributed I/O on Remote I/O 25
Publication 1791R-IN001A-EN-P - February 2002
Sinking or Sourcing Output Specifications (continued)
Indicators Status - red/green/orange
Comm - green
I/O - yellow
Communication Rate 57.6Kbps @ 3048m (10000ft)
115.2Kbps @ 1524m (5000ft)
230.4Kbps @ 762m (2500ft)
General Specifications
Isolation
Auxiliary I/O power to RIO
I/O group-to-group
I/O group-to-RIO
Type tested to 500V ac for 60 seconds
Type tested to 500V ac for 60 seconds
Type tested to 500V ac for 60 seconds
Isolation
Auxiliary I/O power to RIO
I/O group-to-group
I/O group-to-RIO
Type tested to 500V ac for 60 seconds
Type tested to 500V ac for 60 seconds
Type tested to 500V ac for 60 seconds
RIO Power: Voltage
Current
18 - 26.4V dc
250mA maximum (with expansion)
Expansion Power: Voltage
Current
5V dc
100mA
Auxiliary Power Inputs: Voltage
Current
10-30V dc
88mA each group of 8
Auxiliary Power Outputs: Voltage
Current
10-30V dc
4A each group of 8
Base Module Dimensions 150mm X 50mm X 38mm
5.91in X 1.97in X 1.5in
Expansion Module Dimensions 115mm X 50mm X 38mm
4.4in X 1.97in X 1.5in
Field Wiring Tightening Torque 5-7lb-in. (0.5-0.6 Nm)
Operating Temperature IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0 to 60°C (32 to 140°F)
Storage Temperature IEC 60068-2-1 (Test Ab, Un-packaged Non-operating
Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating
Dry Heat),
IEC 60068-2-14 (Test Na, Un-packaged
Non-operating Thermal Shock):
–40 to 85°C (–40 to 185°F)
Relative Humidity IEC 60068-2-30 (Test Db, Un-packaged
Non-operating Damp Heat):
5-95% non-condensing
Shock IEC60068-2-27 (Test Ea, Unpackaged Shock):
Operating 30g
Non-operating 50g
