6 1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Thermocouple and RTD Input Modules
Publication 1732E-IN005B-EN-E - September 2012
Optional Accessories
The following table identifies optional accessories that you can use with the modules that
have to be ordered separately.
Catalog Number Explanation
Refer to the table for a description of the module catalog numbers.
Install the Module
To install the module:
• Set the network address
• Mount the module
• Connect the Functional Ground and Module power/Auxiliary power cables
• Connect the I/O and Network cables to the module
Set the Network Address
The I/O block ships with the rotary switches set to 999 and DHCP enabled.
To change the network address, you can do one of the following:
Option Catalog Number
Snap-in individual marker card
(1)
(1)
Provides labelling for the terminal blocks to allow for easy identification and description.
1492-MD6X9
Cold Junction Compensation Terminal Chamber
(with embedded thermistor)
(2)
(2)
Recommended for use with the 1732E-IT4IM12R module.
871A-TS4CJC-DM or 871A-TR4CJC-DM
Catalog Number Description Network
Connector Power

Connector
1732E-IT4IM12R 24V DC power, 4-Point Isolated Thermocouple
Input, Dual-Port EtherNet/IP Module Dual D-code
M12 Dual 4-pin
micro
1732E-IR4IM12R 24V DC power, 4-Point Isolated RTD Input,
Dual-Port EtherNet/IP Module
