1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Thermocouple and RTD Input Modules 17
Publication 1732E-IN005B-EN-E - September 2012
Specifications
I/O status
Off
The input channel is inactive, can be calibrated.
Flashing Green
Channel is calibrating.
Green
Normal operation, inputs being scanned.
Flashing Yellow
Thermistor fault.
Flashing Red
Fault. Overrange, underrange, or process alarm is present.
Red
No power is detected.
IMPORTANT
The Module Status LED indicator will flash red and green for a maximum
30 s while the module completes its POST (Power-On Self Test).
General Specifications
Attributes
Value
Voltage, power, max
30V DC
Voltage, power, min
12V DC
Module power
12…30V DC @ 300 mA
Power consumption
3 W @ 24V DC, typical
3.5 W, max (module unloaded)
Isolation voltage
50V (continuous), Basic Insulation Type
Type tested @ 707V DC for 60 s
Communication rate
EtherNet/IP
10/100 Mbps
Full or half-duplex
100 meter per segment
Indicator Status for the Modules
Indicator
Status
Description
