1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Thermocouple and RTD Input Modules 21
Publication 1732E-IN005B-EN-E - September 2012
Input range
RTD type
Temperature
Range (°C)
Voltage Range
100
Pt 385
0…390.48
-200…850 °C
0…156.25 mV
200
Pt 385
0…781
-200…850 °C
0…312.5 mV
100
Pt 3916
0…337.03
-200…630 °C
0…156.25 mV
200
Pt 3916
0…674.06
-200…630 °C
0…312.5 mV
10
Cu 427
0…19.116
-320…500 °C
0…19.53 mV
120
Ni 672
0…445.10
-70…445 °C
0…156.25 mV
100
Ni 618
0…198.88
-60…180 °C
0…78.125 mV
120
Ni 618
0…238.65
-90…140 °C
0…78.125mV
Accuracy
0.1% Full Scale @ 25 °C (77 °F)
Accuracy drift with
temperature
30 ppm % Full Scale /°C @ 25 °C (77 °F)
Calibration
Factory calibrated. Calibration is also supported through RSLogix 5000.
Sample Rate
Filters
(1)
50 Hz
60 Hz
250 Hz
500 Hz
Common Mode
Rejection Ratio
120 dB @ 50/60 Hz
Normal Mode
Rejection Ratio
100 dB @ 50/60 Hz
(1)
Sample rate filter selectable on a module basis only.
Input Specifications – 1732E-IR4IM12R
Attributes
Value
