MicroLogix 1762-IF2OF2 Analog Input/Output Module 23
Publication 1762-IN005C-EN-P - July 2013
Output Specifications
Attribute Value
Number of Outputs 2 single-ended (unipolar)
D/A Converter Type Resistor string
Resistive Load on Current Output 0…500 Ω (includes wire resistance)
Load Range on Voltage Output > 1K Ω
Reactive Load, Current Output < 0.1 mH
Reactive Load, Voltage Output < 1 μF
Typical Overall Accuracy (1)
(1) Includes offset, gain, non-linearity and repeatability error terms.
± 1.17% full scale @ -20…65 °C (-4 °F…149 °F)
±0.5% full scale @ 25 °C (77 °F)
Output Ripple range 0…500 Hz
(referred to output range) < ±0.1%
Non-linearity (in percent full scale) < ±0.59%
Open and Short-Circuit Protection Continuous
Output Protection ±32 mA
