MicroLogix 1762-IF2OF2 Analog Input/Output Module 19
Publication 1762-IN005C-EN-P - July 2013
Configuration Data File
The configuration of the format for analog inputs and outputs is made at going to run (GTR).
Changes made to the configuration file while in run mode have no effect.
The configuration table for analog inputs and outputs is shown in the table below.
Bit 15 and Bits 7…0 - Reserved
These bits are reserved and are not checked by the module.
Data Format (Bits 14…12)
These bits indicate the format of the data as shown in the following table. Other combinations of
these bits are not supported and result in an error.
Configuration Data File
Wo
rd
Bit Position
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0
re
se
rved
Data Format Input
Channel 0 Type/Range Select Input
Channel 0 reserved
1 Data Format Input
Channel 1 Type/Range Select Input
Channel 1 reserved
2 reserved
3 reserved
4
re
se
rv
ed
Data Format Output
Channel 0 Type/Range Select
Output Channel 0 reserved
5 Data Format Output
Channel 1 Type/Range Select
Output Channel 1 reserved
6 reserved
7 reserved
Bit Settings Data Format
14 13 12
0 0 0 Raw/Proportional
0 1 0 Scaled for PID
other Not Supported
