52 Powermonitor 3000 Master Module
Publication 1404-IN007F-EN-P - November 2009
Access Self-test and Diagnostic Data
You can access valuable diagnostic information by using the optional display module.
1. Connect the display module to the master module by using the display module cable.
2. Using the four control keys, navigate through the menus to Display - Status and press
Enter.
The display module then displays the following data. Use the up and down arrow keys
to step through the status data.
Display Module Status
Display Description
CAT NO The unit catalog number and series revision letter.
ACC CLASS Displays the revenue-meter accuracy class.
WIN NO The unit’s unique Warranty Identification Number (needed for service and
optional firmware enhancements).
HW REV Displays details of the digital board, analog board, and ASIC revisions.
FRN MASTER
MODULE
Shows the master-module firmware revision.
DEVICE ID Shows the units device ID number assigned at the factory. This number is also
used in the default address for native RS-485, and optional RS-232 and
EtherNet/IP communication.
SELFTEST
STATUS
Displays a status code bitfield as a hex number. A non-zero value indicates an
anomaly.
CODE FLASH Indicates the health of the flash-memory code area.
RAM
Indicates the health of the random access memory.
DATA FLASH Indicates the health of the flash-memory data area.
NVRAM
Indicates the health of the super-cap backed nonvolatile random-access memory.
D ACQ Indicates the data-acquisition system health.
W DOG Indicates the system watchdog-timer status.
CLOCK Indicates the health of the real-time clock.
COMM Displays the firmware revision of the optional communication card (if applicable).
COMM Displays the optional communication-card type.
COMM Displays the optional communication-status bitfield as a hex number (0000 hex is
normal for -232 and -RIO units, and 9001 hex is normal for -DNT and -ENT units).
