Accessory, Din rail bracket for wall or panel mount – Rockwell Automation 1606-XLP50E Power Supply Reference Manual User Manual
Page 16
All parameters are specified at 24V, 2.1A, 230Vac input, 25ªC ambient and after a 5 minutes run-in time unless noted otherwise.
16
Rockwell Automation Publication 1606-RM034A-EN-P — March 2014
Bulletin 1606 Switched Mode Power Supplies
25. Accessory
DIN Rail bracket for wall or panel mount
A DIN rail bracket is included in each shipping box.
Fig. 25-1 DIN Rail Bracket Dimensions
Hole diameter: 4.2mm
1606-XLPRED Dual decoupling module 2x5A
Fig. 25-2 1606-XLPRED Dual Decoupling Module
Fig. 25-3
Redundant System with two 1606-XLP50E
and one 1606-XLPRED
XLPRED
V
OUT
V
IN
1
+ +
- -
+
-
+
-
V
IN
2
1606-
XLP50E
adj.
L N
+ +
-
-
DC
ok
1606-
XLP50E
adj.
L N
+ +
-
-
DC
ok
L
N
PS1 ok
PS2 ok
Load
+
-
I
I
