Rockwell Automation 937CU-DIFRQ_1 Universal Frequency Converter Installation Instructions User Manual
Page 24
Bul. 937
C Universal Frequency Converter Installation Instructions
energized
de-energized
Min
Min + Hysteresis
Max - Hysteresis
Max
energized
de-energized
energized
de-energized
energized
de-energized
Measuring value
Time
Switching direction Max, operating mode Active:
Switching direction Max, operating mode Passive:
Switching direction Min, operating mode Active:
Switching direction Min, operating mode Passive:
22
