The following illustration shows the menus for the input parameters. Menu items on the lowest level are
outlined in bold. Menu items which only appear under certain conditions are marked in grey.
•For lead fault monitoring, terminal 3 is watched to see whether no current is flowing (lead
break(LB)/open circuit) or the input current is too high (short circuit-SC).
Input —— Lead monitor (see below) —— LB —— ON LB
OFF LB
SC —— ON LK
OFF LK
Smoothing (see below) —— 0 sec ... 255 sec
Pulses/unit () —— 1 ... 65000
Bounce filter (see below) —— ON Filter
OFF Filter
Start-up override () —— 1 sec ... 1000 sec
Input
15
