Output, Switching outputs – Rockwell Automation 937CU-DIFRQ_1 Universal Frequency Converter Installation Instructions User Manual
Page 21
Bul. 937
C Universal Frequency Converter Installation Instructions
Output
The following illustrations show the menus for the output parameters.
Switching outputs
From the
Rel1, Rel2 and OT1 menu options, the OK key takes you to a menu in which you can enter
parameters for the selected switch output. The three menus are completely identical and will therefore be
described only once.
When the function of a switch output is activated (
Limit switch, Serial switching, Pulse divider or Error
switch), this is indicated by On. If you want to activate a different function, first select the function with the
and keys. Then press the OK key twice. After the first OK you can still cancel with ESC.
Output
——
Rel1 ()
——
Limit switch
Serial switching
Pulse divider
Error switch
Rel2 ()
—— same menu as Rel1
—— same menu as Rel1
Iout ()
19
