Rockwell Automation 1000 Safety Lockout System - Manual (Page 35)

Publication 1000-UM001B-US-P - July 2000
Certification Documentation A-5
8 Primary Fuses Kldr 0.75 A 25183-272-11 2
9 Secondary Fuse Block 1492-FB1C30-L 1
10 Secondary Fuse Kldr 0.75 A 25183-272-11 1
11 50 W Idec Power Supply PS5R-D24 1
12 100S-85 A MCS Contactor 100S-C85D04C 1
12A MCS Surge Suppressor 100-FSC280 1
12B MCS Auxiliary 2 N.O. 100-SA20 1
13 Pilz Relay PU3Z 24V 1
14 Timing Relay 700-FEA1SU22 1
15 Safety Relay 440R-ZBL220Z24 2
16 MCS Relay 700-CF220D 1
16A Protective Cover 100-SCCA 1
16B MCS Surge Suppressor 100-FSC280 1
17 Terminal Blocks 1492-H1 39
18 End Barrier 1492-N36 1
19 End Anchors 1492-N23 2
20 LED Terminal Blocks 1492-HM2V24 3
21 End Barrier 1492-NM40 3
22 Harting Insert Screw 09330102601 4
23 Harting Insert Screw 09330102701 4
24 Harting Hood 09300100422 4
25 Harting Base 09300100301 4
26 Sealcon CD21AAGY 4
26A Sealcon CD29AAGY 1
27 Harting Male Insert Screw 09330242601 1
28 Harting Female Insert Screw 09330242701 1
29 Harting Hood 09300240421 1
30 Harting Base 09300240301 1
31 A-B Logo 40009-100-52 1
32 Wiring Diagram Y-155798 Rev. M 1
33 User Manual Pub. 1000-UM001A-US-P 1
34 LED Explanation Sheet 49000-082-01 1
35 Warning Label 32005-374-01 1
Table A.C Bulletin 100, 85 A SLS Box with Pilz Relay (Cat. No. 1000-NXSLSV85)
Renewal Parts (Continued)
Item Description Part Number Amount
