2-2

Equipment Description

1500-IN059

C-EN-E – June 2013

Operational Requirements

(cont.)

GE Multilin

Function Description

169/269/269 Plus

369

Bul. 825 Plus

Parameters

Jam Protection

Yes

Undervoltage Protection

Yes (w/metering option)

Yes

Ground Fault Alarm Current

1 – 10 A

0.25 – 25 A

0.01 – 25 A

Ground Fault Trip Current

1 – 10 A

0.25 – 25 A

0.01 – 25 A

Ground Fault Trip Delay Time

1 – 255 s

0 – 255 s

0 s – 5 s

Short Circuit Protection

Yes

Jam Circuit Current

1.5 – 6 (multiple of FLC)

1 – 6 (multiple of FLC)

Underload Trip Current

1 – 1000 A

10 – 99 (percent of FLC)

10 – 100 (percent of FLC)

Underload Trip Time Delay

1 – 255 s

1 – 120 s

Ultimate Trip Current

4 – 12 (multiple of FLC)

2 – 20 (multiple of FLC)

4 – 12 (multiple of FLC)

Winding Alarm Temperature

0 – 200°C

1 – 200°C

0°C – 200°C

Winding Trip Temperature

0 – 200°C

1 – 200°C

0°C – 200°C

Bearing Alarm Temperature

0 – 200°C

1 – 200°C

0°C – 200°C

Bearing Trip Temperature

0 – 200°C

1 – 200°C

0°C – 200°C

Ambient Temperature Sensor Input

Yes

Reset Condition

Auto / Manual

Speed Switch Input

169/269 – No

269 Plus – Yes

Yes Yes

Analog Output

Yes

Communication Modbus

Modbus

DeviceNet,

Modbus

Trip Contacts

1 form C

Alarm Contacts

1 form C

1 form A or B

The 825 Plus core balance/ground fault current transformer (GFCT) input has an operating range of 5 to 500 mA. Care is required to ensure

this input range is not exceeded. When existing CT has a ratio of 50:0.025 (2000:1), the minimum trip level is 10A primary. For lower trip
levels, the core balance/GFCT will need to be replaced with a 100:1 ratio CT. Refer to the catalog number breakdown for part numbers of
various donut CT window sizes.
