Fuse Clip Installation (Switch Rating 600A)
40 - 55 lb-in
400A Fuses (Class H, J, R) 600A Fuses (Class J)
600A Fuses (Class H, R)
2
1
4
3
2
Note: Refer to instructions provided with separately mounted fuse blocks (Catalog Numbers 1491-N621 and 1491-R621).
300 - 350 lb-in
300 - 350 lb-in
1
