10
V-VERB PRO REV2496
3.3.1 Simple editing
Immediately after loading a preset, you will be in the recall
level. Here, you have access to four parameters for an effect
(see table 3.1). The selection of these four parameters was
made to let you quickly and simply modify the most important
effect parameters.
Fig. 3.1: Engine A (recall page)
With controls EDIT A, B, C and D you can adjust the values of
these four parameters. The parameters and the current values
are shown in the bottom portion of the display. EDIT D is in this
case always assigned to the effect volume (FX Level), to the
mix (with modulation effects) or to the gain (compressor).
Ef f ec t EDIT A EDIT B EDIT C EDIT D
V -V erb Dec ay ER/Rev ER Size FX Lev el
Concert Predelay Decay ER/Rev FX Lev el
Cathedral Predelay Decay ER/Rev FX Lev el
Theater Predelay Decay ER/Rev FX Lev el
Gold Plate Predelay Decay ER/Rev FX Lev el
A mbience Predelay Decay Siz e FX Lev el
Gated Predelay Dens ity Decay FX Lev el
Rev erse Predelay Ris e Decay FX Lev el
Delay Predelay Delay 1 Delay 2 FX Lev el
X-over Delay Delay 1 Delay 2 Delay 3 FX Lev el
Chorus/Flanger Speed Mod Dly Feedb Mix
Phas er Speed Depth Reson Mix
Tremolo Speed Phas e LFO Mod Mix
Compres sor Thresh Ratio A ttack M-Gain
Tab. 3.2: Parameters with direct access (recall level)
3.3.2 Extensive editing in EDIT mode
Press the EDIT key to get to the EDIT mode. The display now
shows the first of the four EDIT pages. You can scroll back and
forth through individual pages using PAGE / . There is a
maximum of eight parameters per page. If two parameter controls
are shown in the display above one another, press EDIT to
alternate between the top and the bottom parameter.
Fig. 3.2: EDIT page 1
+
The effect algorithm for a preset can not be selected.
If you wish to edit a preset, first load a program
based on the preset. The ROM presets 001 to 014
contain the algorithms 1 to 14.
+
A more detailed description of individual parameters
can be found in chapter 4 “EFFECTS.”
3.3.3 Editing engines in GRAPH mode
Within the EDIT operating mode, the GRAPH mode lets you edit
parameters with graphic visualization. Almost every EDIT page
has its own GRAPH page. By pressing the GRAPH key, you can
switch between the EDIT menu and the GRAPH menu at any
time.
Fig. 3.3: GRAPH mode
When you are on the GRAPH pages, you have direct access
to a maximum of four parameters that can be modified with EDIT
A - D. With some effects, you can press the EDIT control to
alternate between two parameters. This way, you have access
to the four most important parameters for an effect.
3.4 Editing combinations
Press the COMBI. key to get to the combinations level. The
vertical bar on the left in the display shows “A + B.”
Fig. 3.4: Combination recall page
When in recall mode, you can use the controls EDIT A and
EDIT B to adjust the two most important engine A parameters; or
you can use EDIT C and EDIT D to adjust the two most important
engine B parameters.
When in the EDIT mode (EDIT key pressed), you can modify
two level parameters for each engine. These two parameters
(with the exception of the compressor effect) can be muted by
pressing the EDIT infinitely variable rotary control. When you
leave the EDIT mode, the mute function is automatically cancelled.
Fig. 3.5: EDIT page of a combination effect
Effects and the editable parameters are shown below:
3. OPERATION
