Page 21
Rockwell Automation Publication 1608N-UM002A-EN-P - May 2014
21
Appendix
A
Special Instructions for
Model 1608N-012A120V2S-R
Rack-Mount MiniDySC
MiniDySC model 1608N-012A120V2S-R is configured to protect line-corded
loads in a 19-inch IT rack environment.
Amended specifications and dimensions for this model are listed in
. All
other specifications, including environmental and certifications, are as listed in
. This model does not include alarm contacts. LED indicators are front-
facing.
Included mounting hardware will accommodate any of the mounting
orientations shown in
, including 4-post mounting in racks up to 26 in.
deep.
This MiniDySC model contains no user-serviceable parts.
ATTENTION: DO NOT REMOVE THE TOP COVER. WARRANTY WILL BE VOIDED IF IT
IS REMOVED.
