Viewing the Option Module Web Pages Chapter 8
Navigation Pane on Option Module Web Pages
The navigation pane appears on the left side of the option module Home Page
and all of the module's other web pages. The navigation pane consists of links and
link folders which can be expanded or minimized. The following table shows all
navigation menu links and link folders.
Information on Option Module Home Page
The option module Home Page displays the following information for the host
PowerFlex 750-series drive and its option module.
Navigation Pane
Link/Folder
Description
Home link
Click this link to view the module's Home Page (
).
Process display link
Click this link to view the host drive's Process Display pop-up dialog box
(
Profinet configuration link
Click this link to view the module’s Profinet Configuration web page
showing information about the Profinet configuration, such as the
module’s IP address, subnet mask, gateway address, and so forth.
shows an example Profinet Configuration web page.
Configure e-mail
notification link
Click this link to view the module's Configure E-mail Notification web
page (
) to configure the option module to send automatic e-mail
messages. An example e-mail message is shown in
Browse devices folder
Click this folder to expand and view the Port folders for all present
devices, including the drive, option module, and other devices
connected to the drive such as a HIM.
Port x folders
Click a respective Port folder to expand and view its device’s various
links which take you to related information pages. For Port 0 (PowerFlex
750-Series drive) example information pages, see
,
,
and
Online user manuals link
Click this link to view Rockwell Automation’s web page with
documentation for drives and other devices.
Software tools Web site
link
Click this link to view Allen-Bradley’s web page with information about
software tools such as DriveExplorer and DriveExecutive.
Launch my DriveExplorer
software link
Click this link to launch the DriveExplorer software already installed on
your computer.
Launch my DriveExecutive
software link
Click this link to launch the DriveExecutive software already installed
on your computer.
E-mail technical support
link
Click this link to view a new e-mail message window to send a
message to the Allen-Bradley Technical Support Team.
Device
Information
Adapter - 20-750-PNET
(Option Module)
• Revision
• IP Address
• Ethernet Address (MAC)
• Serial Number
• Status
• I/O Connection Status
Host PowerFlex 750-Series
Drive
• Revision
• Status
• Commanded Direction
• Rotation Direction
• Process Status
