12 Guardmaster® EtherNet/IP™ Network Interface

Publication 440R-IN078A-EN-P - January 2014

3. Use a small flat blade screwdriver to pull down the DIN rail locking clip

and lift the module off the DIN rail.

4. Position the replacement interface vertically above the DIN rail.

5. Slide the interface down, positioning it within 5mm of the adjacent

Guardmaster safety relay.

6. Press firmly to seat the interface on the DIN rail, until the module locks

into position.

7. Set the network address on the network address rotary switches.

8. Insert the removable terminal block into the interface.

9. Reconnect the Ethernet cable(s) to the interface.

10. Set the IP address for this module.

WARNING: If you connect or disconnect the communications cable
while power is applied to this module or any device on the network,
an electrical arc can occur. This could cause an explosion in
hazardous location installations.

Be sure that power is removed or the area is nonhazardous before
proceeding.
