6 GuardMaster MSR57P Speed Monitoring Safety Relay
Publication 440R-IN016B-EN-P - November 2008
Specifications
GuardMaster MSR57P Speed Monitoring Safety Relay – 440R-S845AER-NNL
Attribute Value
Standards IEC/EN60204-1, ISO12100, IEC 61800-5-2
Safety category Cat. 4 and PL e per EN ISO 13849-1; SIL CL1 to CL3 per IEC 61508/EN62061
Power supply
24V dc, 0.8…1.1 x rated voltage (3) PELV/SELV
(3) Safety outputs need additional fuse for reverse voltage protection of the control circuit. Install a 6 A slow-blow or 10 A
fast-acting fuse.
Aggregate current of
MSR57P 10.4 A max. @ terminal A1 + 13
Power consumption 5 W
Outputs 14, 24, 68, 78 24V dc, 2 A, short-circuit protected
Outputs 34, 44 24V dc, 100 mA, short-circuit protected
Outputs Y35, Y37 24V dc, 50 mA, short-circuit protected
Door switches 51, 52 (1)
(1) For information on using these outputs in bipolar or cascading configurations, refer to the GuardMaster Speed Monitoring
Safety Relay, publication 440R-UM004.
24V dc, short-circuit protected
•
1.5 A, bipolar (Power to Release/Power to Lock) configuration
• 20 mA, cascading (2 Channel Source) configuration
Outputs Y32, Y33 24V dc, 100 mA, short-circuit protected
Output Y1 24V dc, 20 mA, short-circuit protected
Pulse outputs S11, S21 24V dc, 100 mA, short-circuit protected
Pulse inputs S12, S22,
S32, S42, S52, S62,
S72, S82, X32, X42 11 mA per input, max
Inputs S34, Y2 11 mA per input, max
Power-on delay, max 3 s
Response time
User-configurable.
(4)
(4) Refer to the GuardMaster MSR57P Speed Monitoring Safety Relay User Manual, publication 440R-UM004 for details.
Pollution degree 2
Enclosure protection IP40
Terminal protection IP20
Wire Type Use copper that will withstand 60/75 °C (140/167 °F)
Conductor size (2)
(2) Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
0.2…2.5 mm 2 (12…24 AWG)
Terminal screw torque 0.6…0.8 Nm (5…7 lb-in)
Case material Polyamide PA 6.6
Mounting 35 mm DIN rail
Weight, approx. 350 g (0.77 lb)
