Rockwell Automation 20B PowerFlex 700 Drive Components Replacement - Frame 8 User Manual
Page 10
10
Rockwell Automation Publication 20B-IN024C-EN-P - June 2012
Preface
Refer to the master parts list for the most recent information:
Miscellaneous
(continued)
Bus Capacitor Kit
SK-G1-BUSCAP1-F8
365A, 415A and 481A only.
Includes one capacitor.
Drive requires 18 kits.
SK-G1-BUSCAP2-F8
535A and 600A only.
Includes one capacitor.
Drive requires 18 kits.
Capacitor Bus Finger Kit
SK-G1-FLXBUS1
Included with the kit for inverter
power module (IGBT).
Can be ordered separately.
Includes:
•
Three positive flexible capacitor
busbars
•
Three negative flexible capacitor
busbars
MOV Surge Suppressor
SK-G1-MOV1-F89
AC input.
Power Supply, 24V
SK-G9-PWRS24
DC Link Choke
SK-G1-DCCHOKE1-F8
AC input.
Transformer, 500 VA
SK-G9-XFMR1-F89
AC input.
Includes
•
One transformer
•
Three fuses
Transformer Fuses
SK-G9-FUSE1-F8
AC input.
Includes three fuses.
Balancing Resistor
1336-RLOAD-SP3A
Includes one resistor.
IMPORTANT
Refer to the instruction sheet included with each component kit for
instructions regarding discarding or returning replaced components.
If discarding, be sure to discard according to local, state, and federal
regulations.
Description
Kit Catalog No.
Notes
