13
42CRC Color Registration Control
Dimensions 3.80 L X 2.95 H X 1.31 D . . . . . . . . . . . . . . . . . . . . . . . .
(97mm L X 75mm H X 33mm D)
Weight 12 oz (350 g) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Temperature --13F (--25C) to 167F (75C) . . . . . . . . . . . . . . . .
Operating Ambient Temp. Range 32F (0C) to 158F (70C) . . . . . . . . .
Max Relative Humidity 95% . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cable Assembly #60-2292
(Order Separately) 10 Feet (3m) 5 conductor with shield, . . . . . . . .
#22 AWG (26 X 36) Stranded. Flexible
mount PVC jacket 260 nominal O.D.
rated UL 2661 — 150C 300 volts. 5 pin
(female) watertight connector.
Agency Approvals UL listed, CSA certified . . . . . . . . . . . . . . . . . . . . . . .
Specifications
(Continued)
