12
42CRC Color Registration Control
Voltage Supply: 10V to 30VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Current Consumption 70mA Max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output: Model 4000 Open Collector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NPN (Current Sink)
Model 4001 Open Collector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PNP (Current Source)
Output Rated Load Current (On-State) 100mA . . . . . . . . . . . . . . . . . . . . .
Output Rated Load Voltage (Off-State) 30VDC . . . . . . . . . . . . . . . . . . . . .
Output Short Circuit Protection Continuous . . . . . . . . . . . . . . . . . . . . . . . .
Response Time at Maximum Contrast
(Black & White) 250 Microseconds . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Minimum Web Velocity 2 Inches per sec. . . . . . . . . . . . . . . . . . . . . . . . . . .
(51mm per second)
Maximum Output Dwell 250 Milliseconds min. . . . . . . . . . . . . . . . . . . . .
Minimum Output Dwell
(Overridden by Signal Duration) 250 Microseconds . . . . . . . . . . . . . . .
Transmitter LED’s
(Selectable Red or Green) Visible Red, 630 nm . . . . . . . . . . . . . . . . . . .
Visible Green, 570 nm
Minimum Useable Mark to Background Voltage
Change (Measured at Test Points in Manual Mode)
Manual Mode 250 Millivolts D.C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Mode 500 Millivolts D.C. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scanning Distance 0.5 (13mm) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Depth of Field +/-- .08 (2mm) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Min. Size of Mark
at Scanning Distance 0.08 X .10 (2mm X 2.5mm) . . . . . . . . . . . . . . . .
False Pulse Suppression Yes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reverse Polarity Protection Yes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
External Gating Mode Yes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Latching Output Mode with External Reset Yes . . . . . . . . . . . . . . . . . . . .
Diagnostic Alarm Following seven successive marks . . . . . . . . . . . .
below margin of 1.5 X, or loss of power.
Diagnostic Alarm Output N.C. Open collector NPN output, . . . . . .
30mA max., 30VDC max.
Operating Environment Housing made of #380.0 cast aluminum . . . . . . .
Anodized and epoxy coated for
corrosion resistance. Rated for NEMA 3,
4, 6P, 12, and 13. IP67 (IEC 529)
Test Points for Contrast Check Yes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
